Hyundai i30 Fastback N Makes Debut at Paris

by Oct 2, 2018All News, Hyundai, N-Performance, Paris 20180 comments

hyundai i30 fastback n paris motor show 2

Here you can find the technical data and dimensions of the All-New Hyundai i30 Fastback N alongside live pictures and video of the latest N performance model from Hyundai showcased at Paris Motor Show.

GASOLINE: THETA 2.0 T-GDI (250 PS)**
Type THETA 2.0 T-GDI, 16-valve MLA, DOHC E-CVVT
Capacity 1,998 cc
Bore x stroke 86.0 x 86.0 mm
Compression ratio 9.5
Power 250 PS (184 kW) @ 6,000 rpm
Torque 353 Nm @ 1,450 ~4,000 rpm
378 Nm with Overboost Function
Maximum speed (km/h) 250
0-100 km/h (seconds) 6.4
CO2 combined (g/km)* 176
Fuel consumption combined (l/100 km)* 7.7
Fuel consumption urban (l/100 km)* 10.7
Fuel consumption extra-urban (l/100 km)* 5.9
GASOLINE: THETA 2.0 T-GDI with Performance Package (275 PS)**
Type THETA 2.0 T-GDI, 16-valve MLA, DOHC E-CVVT
Capacity 1,998 cc
Bore x stroke 86.0 x 86.0 mm
Compression ratio 9.5
Power 275 PS (202 kW) @ 6,000 rpm
Torque 353 Nm @ 1,450 ~4,700 rpm
378 Nm with Overboost Function
Maximum speed (km/h) 250
0-100 km/h (seconds) 6.1
CO2 combined (g/km)* 178
Fuel consumption combined (l/100 km)* 7.8
Fuel consumption urban (l/100 km)* 10.6
Fuel consumption extra-urban (l/100 km)* 6.1

https://twitter.com/HyundaiPR_es/status/1047035253192314880

Transmissions

Gasoline engines – speeds

Engine Manual
2.0 T-GDI (250 PS) 6
2.0 T-GDI (275 PS) 6

Gear ratios**

Gear ratio THETA 2.0 T-GDI
STD (250 PS)
1st 3,083
2nd 1,931
3rd 1,696
4th 1,276
5th 1,027
6th 0,754
Reverse 3,588
Final gear ratio 4,154 (1/2/R)
3,176 (3/4/5/6)
Gear ratio THETA 2.0 T-GDI
P PKG (275 PS)
1st 3,083
2nd 1,931
3rd 1,696
4th 1,276
5th 1,027
6th 0,854
Reverse 3,588
Final gear ratio 4,333 (1/2/R)
3,250 (3/4/5/6)

hyundai i30 fastback n paris motor show

Suspension

Front McPherson Strut
Rear Multi-Link

Steering**

Type R-MDPS (RACK TYPE MOTOR DRIVEN POWER STEERING)
General RACK & PINION
Overall steering gear ratio Std. Package: 12.26 (@360°)
Perf. Paackge: 12.31 (@360°)
Steering wheel turns (Lock to lock) 2.14
Min. turning radius (m) 5.8

Brakes*

Front Disc Type, 17″ (Standard) / 18″ (Performance Package)
Rear Disc Type, 16″ (Standard) / 17″ (Performance Package( (HAND PARKING)
Master cylinder Φ23.81
Booster size 10″ (LHD, RHD)

https://twitter.com/HyundaiPR_es/status/1047086729579106304

Wheels and tyres

Wheel type Tyres
7.5Jx18 AL 225/40R18
8.0Jx19 AL 235/35R19

Dimensions (mm)**

Exterior

Overall length 4,455
Overall width 1,795
Overall height 1,417 (Standard)
1,419 (Performance Package)
Wheelbase 2,650
Front overhang 905
Rear overhang 900
Ground clearance 132

Capacities**

Fuel tank (litres) 50
Luggage space (litres) Minimum 450 (436 with rear stiffness bar)
Maximum 1,351 (1,337 with rear stiffness bar)
